Construction Products Regulation

The European Construction Product Regulation 305/2011 (CPR for short) sets uniform rules for the use of building products within buildings for all EU member states. The implementation of the CPR is regulated by DIN EN 50575: 2017-02. The objective of the CPR / DIN EN 50575 is to increase the fire safety in buildings.






As of July 1st, 2017, the coaxial cables of SSB-Electronic GmbH have a corresponding fire classification and service agreement, as the CPR provides. Correspondingly, the coaxial cables are CE marked.

The CE marking is clearly visible, readable and permanent on the product label.

Additional labeling, such as origin, description and fire behavior, can also be found in the labeling. As a manufacture, we provide each tested cable with a service declaration, which contains precise information about the fire behavior, which you can download at any time from our website.




Coaxial CableEuroclass according to
 EN 50575		Building Fire Safety
 Requirements		Application AreaClassification CriteriaAVCP System
 (Assessment and Verification of
 Constancy of Performance)
Aircell 5EcalowCables for standard applications:
 in buildings with low height or low volume of occupants, in appartments
Flame propagation
 EN 60332-1-2
 H ≤ 425 mm

System 3:
 Initial type-testing by third-party notified testing laboratory

 Factory production control (FCB) by manufacturer

Aircell 7
Ecoflex 10
Ecoflex 10 PLUS
Ecoflex 15
Ecoflex 15 PLUS
Aircom Premium
Ecoflex Multicore
Ecoflex 10 PLUS
 Heatex

 Ecoflex 10 FRNC


 		Cca
 s1 d0 a1		highCables for areas with
 increased fire risk:
 in tower buildings,
 facilities, administration & office buildings, commercial buildings,
 restaurants, hotels,
 underground parking,
 schools, prisons, leisure facilities, etc.
Flame propagation
 EN 60332-1-2
 H ≤ 425 mm

 Heat release,
 vertical
 Flame spread
 EN 50399
 FS ≤ 2,0 m
 THR ≤ 30 MJ
 max. HRR ≤ 60 kW
 FIGRA ≤ 300 W/s
 flame source = 20,5 kW

 Smoke production
 EN 50399/EN 61034-2
 s1, s1a, s1b, s2, s3

 Acidity/Corrosivity
 EN 60754-2
 a1, a2, a3

 Flaming droplets
 EN 50399
 d0, d1, d2		System 1+:
 Initial type-testing by third-party notified product certification body

 Continuous factory inspection by third-party notified product certification body

 Continuous audit testing of samples by third-party notified product certification body


Factory production control (FCB) by manufacturer







Ecoflex 15 PLUS
 Heatex

 Ecoflex 15 FRNC




 		Cca
 s2 d2 a1
Aircell 5 Heatex

 Aircell 7 Heatex		Cca
 s1 d0 a1
LCF14-50JFN
 (RFS)		B2ca
 s1a d1 a1		very highCables for areas with
 high fire risk:
 in hospitals, care facilities,
 day-care centers for children,
 server rooms, road and
 railway tunnels, facilities for storing substances with an increased risk of fire, etc.


SCF38-50JFN
 SCF12-50JFN
 LCF12-50JFN
 LCF78-50JFNA
 (RFS)		B2ca
 s1a d0 a1



Download Declaration of Performance (DoP) of SSB cables:


Download Declaration of Performance (DoP) of RFS CELLFLEX® cables:


All CELLFLEX® SCF/LCF cables with jacket option "J" have the Euroclass "F / not classified" because none of the CPR classes are fulfilled.


Euroclass of RFS RADIAFLEX® cables:

CableJacket option
 JFNAJFLACPR
RADIAFLEX® RLK types 1/2"Cca s1a d1 a1Cca s1a d0 a1B2ca s1a d0 a1
RADIAFLEX® RCF types 1/2"Cca s1a d1 a1not availablenot available
RADIAFLEX® RLK types 7/8"Dca s1b d2 a1Dca s1b d2 a1B2ca s1a d0 a1
RADIAFLEX® RLF types 7/8"Dca s1b d2 a1Dca s1b d2 a1B2ca s1a d0 a1
RADIAFLEX® RAY types 7/8"Dca s1b d2 a1Dca s1b d2 a1B2ca s1a d0 a1


Download Declaration of Performance (DoP) of RFS RADIAFLEX® cables:


Euroclass of fibre optic cables from DÄTWYLER:


CableItem no.
 DÄTWYLER		Reaction to fire
FO Universal ZGGFR 1x4 E9/125 G.652.D OS219020300DZDca-s2,d1,a1
FO Universal ZGGFR 1x8 E9/125 G.652.D OS219020500DZDca-s2,d1,a1
FO Universal ZGGFR 1x12 E9/125 G.652.D OS219007700DZDca-s2,d1,a1
FO Universal ZGGFR 2x12 E9/125 G.652.D OS219007100DZDca-s2,d1,a1
FO Universal wbGGFR 4x12 E9/125 G.652.D OS219020800EZEca
FO Universal ZGGFR 1x4 G50/125 OM318598900DZDca-s2,d1,a1
FO Universal ZGGFR 1x8 G50/125 OM318595900DZDca-s2,d1,a1
FO Universal ZGGFR 1x12 G50/125 OM318635000DZDca-s2,d1,a1
FO Universal ZGGFR 2x12 G50/125 OM318643200DZDca-s2,d1,a1
FO Universal wbGGFR 4x12 G50/125 OM318648600EZEca
FO Universal ZGGFR 1x4 G50/125 OM419271200DZDca-s2,d1,a1
FO Universal ZGGFR 1x8 G50/125 OM418736300DZDca-s2,d1,a1
FO Universal ZGGFR 1x12 G50/125 OM419125100DZDca-s2,d1,a1
FO Universal ZGGFR 2x12 G50/125 OM419125200DZDca-s2,d1,a1
FO Universal wbGGFR 4x12 G50/125 OM419127800EZEca



Download Declaration of Performance (DoP) of fibre optic cables from DÄTWYLER:


The products of SSB-Electronic GmbH are therefore safe, tested, classified and thus fully comply with European legislation.


Quality Made in Germany.
